Product Name:	Human PIEZO1 (Piezo-type mechanosensitive ion channel component 1) ELISA Kit
Product Code:	HUFI04961
Size:	96 Assays
Alias:	FAM38A ELISA Kit, KIAA0233 ELISA Kit, Mib ELISA Kit, PIEZO1 ELISA Kit
Detection method:	Sandwich ELISA, Double Antibody
Application:	This immunoassay kit allows for the in vitro quantitative determination of Human PIEZO1 (Piezo-type mechanosensitive ion channel component 1) concentrations in serum plasma and other biological fluids.
Sensitivity:	< 0.188ng/ml
Range:	0.313-20ng/ml
Storage:	4°C for 6 months
Note:	For Research Use Only

Recovery:

Matrices listed below were spiked with certain level of Human PIEZO1 (Piezo-type mechanosensitive ion channel component 1) and the recovery rates were calculated by comparing the measured value to the expected amount of Human PIEZO1 (Piezo-type mechanosensitive ion channel component 1) in samples.

Matrix	Recovery range(%)	Average(%)
serum(n=5)	85-105	94
EDTA plasma(n=5)	87-101	94
heparin plasma(n=5)	86-105	97

Linearity:

The linearity of the kit was assayed by testing samples spiked with appropriate concentration of Human PIEZO1 (Piezo-type mechanosensitive ion channel component 1) and their serial dilutions. The results were demonstrated by the percentage of calculated concentration to the expected.

Sample	1:2	1:4	1:8
serum(n=5)	88-102%	85-96%	90-104%
EDTA plasma(n=5)	82-92%	83-99%	88-101%
UFH plasma(n=5)	88-100%	86-100%	85-98%

CV(%):

Intra-Assay: CV<8%
Inter-Assay: CV<10%

Component	Quantity	Storage
ELISA Microplate (Dismountable)	8×12 strips	4°C for 6 months
Lyophilized Standard	2	4°C/-20°C
Sample/Standard Dilution Buffer	20ml	4°C
Biotin-labeled Antibody(Concentrated)	120ul	4°C (Protect from light)
Antibody Dilution Buffer	10ml	4°C
HRP-Streptavidin Conjugate(SABC)	120ul	4°C (Protect from light)
SABC Dilution Buffer	10ml	4°C
TMB Substrate	10ml	4°C (Protect from light)
Stop Solution	10ml	4°C
Wash Buffer(25X)	30ml	4°C
Plate Sealer	5	-

Other materials and equipment required:

Microplate reader with 450 nm wavelength filter
Multichannel Pipette, Pipette, microcentrifuge tubes and disposable pipette tips
Incubator
Deionized or distilled water
Absorbent paper
Buffer resevoir

UniProt Protein Function:	PIEZO1: Component of mechanosensitive channel required for the mechanosensitive currents. Plays a key role in epithelial cell adhesion by maintaining integrin activation through R-Ras recruitment to the ER, most probably in its activated state, and subsequent stimulation of calpain signaling. Belongs to the PIEZO family.
UniProt Protein Details:	Protein type:Endoplasmic reticulum; Membrane protein, integral; Membrane protein, multi-pass Chromosomal Location of Human Ortholog: 16q24.3 Cellular Component: endoplasmic reticulum membrane; ER-Golgi intermediate compartment membrane; endoplasmic reticulum; integral to membrane; plasma membrane Molecular Function:mechanically-gated ion channel activity; cation channel activity Biological Process: regulation of membrane potential; detection of mechanical stimulus; positive regulation of cell-cell adhesion mediated by integrin; positive regulation of integrin activation; cation transport Disease: Dehydrated Hereditary Stomatocytosis With Or Without Pseudohyperkalemia And/or Perinatal Edema
NCBI Summary:	Piezos are large transmembrane proteins conserved among various species, all having between 24 and 36 predicted transmembrane domains. 'Piezo' comes from the Greek 'piesi,' meaning 'pressure.' The FAM38A gene encodes PIEZO1, a protein that induces mechanically activated (MA) currents in various cell types (Coste et al., 2010 [PubMed 20813920]).[supplied by OMIM, Nov 2010]
UniProt Code:	Q92508
NCBI GenInfo Identifier:	317373533
NCBI Gene ID:	9780
NCBI Accession:	Q92508.4
UniProt Secondary Accession:	Q92508,Q0KKZ9, A6NHT9, A7E2B7,
UniProt Related Accession:	Q92508
Molecular Weight:	2521
NCBI Full Name:	Piezo-type mechanosensitive ion channel component 1
NCBI Synonym Full Names:	piezo-type mechanosensitive ion channel component 1
NCBI Official Symbol:	PIEZO1
NCBI Official Synonym Symbols:	DHS; Mib; FAM38A
NCBI Protein Information:	piezo-type mechanosensitive ion channel component 1; family with sequence similarity 38, member A; membrane protein induced by beta-amyloid treatment
UniProt Protein Name:	Piezo-type mechanosensitive ion channel component 1
UniProt Synonym Protein Names:	Membrane protein induced by beta-amyloid treatment; Mib; Protein FAM38A
Protein Family:	Piezo-type mechanosensitive ion channel component
UniProt Gene Name:	PIEZO1
UniProt Entry Name:	PIEZ1_HUMAN

*Note: Protocols are specific to each batch/lot. For the correct instructions please follow the protocol included in your kit.

Before adding to wells, equilibrate the SABC working solution and TMB substrate for at least 30 min at 37 °C. When diluting samples and reagents, they must be mixed completely and evenly. It is recommended to plot a standard curve for each test.

Step	Protocol
1.	Set standard, test sample and control (zero) wells on the pre-coated plate respectively, and then, record their positions. It is recommended to measure each standard and sample in duplicate. Wash plate 2 times before adding standard, sample and control (zero) wells!
2.	Aliquot 0.1ml standard solutions into the standard wells.
3.	Add 0.1 ml of Sample / Standard dilution buffer into the control (zero) well.
4.	Add 0.1 ml of properly diluted sample ( Human serum, plasma, tissue homogenates and other biological fluids.) into test sample wells.
5.	Seal the plate with a cover and incubate at 37 °C for 90 min.
6.	Remove the cover and discard the plate content, clap the plate on the absorbent filter papers or other absorbent material. Do NOT let the wells completely dry at any time. Wash plate X2.
7.	Add 0.1 ml of Biotin- detection antibody working solution into the above wells (standard, test sample & zero wells). Add the solution at the bottom of each well without touching the side wall.
8.	Seal the plate with a cover and incubate at 37 °C for 60 min.
9.	Remove the cover, and wash plate 3 times with Wash buffer. Let wash buffer rest in wells for 1 min between each wash.
10.	Add 0.1 ml of SABC working solution into each well, cover the plate and incubate at 37 °C for 30 min.
11.	Remove the cover and wash plate 5 times with Wash buffer, and each time let the wash buffer stay in the wells for 1-2 min.
12.	Add 90 µL of TMB substrate into each well, cover the plate and incubate at 37 °C in dark within 10-20 min. (Note: This incubation time is for reference use only, the optimal time should be determined by end user.) And the shades of blue can be seen in the first 3-4 wells (with most concentrated standard solutions), the other wells show no obvious color.
13.	Add 50 µL of Stop solution into each well and mix thoroughly. The color changes into yellow immediately.
14.	Read the O.D. absorbance at 450 nm in a microplate reader immediately after adding the stop solution.

When carrying out an ELISA assay it is important to prepare your samples in order to achieve the best possible results. Below we have a list of procedures for the preparation of samples for different sample types.

Sample Type	Protocol
Serum	If using serum separator tubes, allow samples to clot for 30 minutes at room temperature. Centrifuge for 10 minutes at 1,000x g. Collect the serum fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles. If serum separator tubes are not being used, allow samples to clot overnight at 2-8°C. Centrifuge for 10 minutes at 1,000x g. Remove serum and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles.
Plasma	Collect plasma using EDTA or heparin as an anticoagulant. Centrifuge samples at 4°C for 15 mins at 1000 × g within 30 mins of collection. Collect the plasma fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles. Note: Over haemolysed samples are not suitable for use with this kit.
Urine & Cerebrospinal Fluid	Collect the urine (mid-stream) in a sterile container, centrifuge for 20 mins at 2000-3000 rpm. Remove supernatant and assay immediately. If any precipitation is detected, repeat the centrifugation step. A similar protocol can be used for cerebrospinal fluid.
Cell culture supernatant	Collect the cell culture media by pipette, followed by centrifugation at 4°C for 20 mins at 1500 rpm. Collect the clear supernatant and assay immediately.
Cell lysates	Solubilize cells in lysis buffer and allow to sit on ice for 30 minutes. Centrifuge tubes at 14,000 x g for 5 minutes to remove insoluble material. Aliquot the supernatant into a new tube and discard the remaining whole cell extract. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
Tissue homogenates	The preparation of tissue homogenates will vary depending upon tissue type. Rinse tissue with 1X PBS to remove excess blood & homogenize in 20ml of 1X PBS (including protease inhibitors) and store overnight at ≤ -20°C. Two freeze-thaw cycles are required to break the cell membranes. To further disrupt the cell membranes you can sonicate the samples. Centrifuge homogenates for 5 mins at 5000xg. Remove the supernatant and assay immediately or aliquot and store at -20°C or -80°C.
Tissue lysates	Rinse tissue with PBS, cut into 1-2 mm pieces, and homogenize with a tissue homogenizer in PBS. Add an equal volume of RIPA buffer containing protease inhibitors and lyse tissues at room temperature for 30 minutes with gentle agitation. Centrifuge to remove debris. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
Breast Milk	Collect milk samples and centrifuge at 10,000 x g for 60 min at 4°C. Aliquot the supernatant and assay. For long term use, store samples at -80°C. Minimize freeze/thaw cycles.
